Orolia logo The industry-leading Spectracom products you depend on are now brought to you by Orolia, Spectracom’s parent company. Orolia is the world leader in resilient positioning, navigation and timing (PNT) solutions that improve the reliability, performance and safety of critical, remote or high-risk operations. Orolia provides virtually failsafe GPS/GNSS and PNT solutions to support government and commercial applications worldwide.

Assured Positioning, Navigation and Timing (PNT)

Assured positioning, navigation and timing (PNT) is mandatory for the reliability, performance and safety of mission-critical applications in the air, on land and in the sea.

VersaPNT Orolia VersaPNT

Next-generation resilient position, navigation, and timing in a small, rugged package.
VersaPNT is the first all-in-one, always-accurate positioning, navigation and timing solution that delivers accurate, software-configurable position, navigation, altitude, time, and frequency signals under all circumstances.

Accurate in All Conditions

  • GNSS-aided inertial navigation and timing
  • High performance internal time base and inertial sensor to manage potential GNSS loss
  • GNSS time and frequency source with NTP/PTP time server
  • Ability to integrate future PNT signal sources such as alternative signals, CAN Bus, etc.

Flexible

  • High versatility with software-configurable inputs/outputs
  • Network sync, set up and management
  • Easy integration, with small footprint and low power consumption
  • Compatible with external IMUs
  • Victory compatible
  • Measurement data is logged internally and streamed through a serial or LAN interface

Compact and Rugged

  • Ruggedized (MIL-STD-810G) low size, weight and power
  • Conduction-cooled
  • Mil-performance connectors
  • Standby power mode
  • Configurable for multiple vehicle and airframe platforms

Download Orolia VersaPNT datasheet

VersaSync

VersaSync is a high performance GPS master clock and network time server that delivers accurate, software configurable time and frequency signals under all circumstances, including GNSS-denied environments. Its compact size and high level of ruggedization make VersaSync suitable for mobile applications in harsh environments. Its small footprint allows for easy integration of the time and frequency functionality into systems architecture.

All-in-One Time and Frequency SolutionOrolia VersaSync

  • GNSS master clock and NTP/PTP time server
  • Low size, weight and power
  • Ruggedized (MIL-STD-810G)
  • High versatility with software configurable inputs/outputs
  • Design can be efficiently customized to match specific customer requirements
  • Easy integration due to small footprint and low power consumption

Timing Functionality for Modern, Network-centric Applications

  • NTP/PTP precise time transfer over Ethernet, including security protocols that prevent network vulnerabilities
  • Low phase noise 10 MHz frequency distribution
  • Configurable pulse signals, including IRIG or HaveQuick timecodes
  • Serial link Time Of Day (ToD) messages
  • OCXO or CSAC oscillator to maintain frequency and time accuracy for long periods of GPS/GNSS outage

Download VersaSync datasheet

Multi-Channel Multi-Frequency GPS/GNSS Simulators

GSG-8 Series

GSG-8 is the newest positioning, navigation, and timing test solution offered through Orolia’s GSG family of simulators. It was developed to deliver the highest standard of Global Navigation Satellite System (GNSS) signal testing and sensor simulation performance in an easy to use, upgradable and scalable platform. Key features:Orolia GSG-8
  • Flexible software defined platform
  • 1000Hz simulation iteration rate
  • Live sky time synchronization
  • On-the-fly scenario reconfiguration
  • 6 Degrees of Freedom (DoF) receiver trajectories
  • Flexible licensing
  • In-field upgradability
  • High-end performance (precision, resolution, ultra-high dynamic motion)
  • Simulate hundreds of satellites in real time, using off-the-shelf graphics cards (GPU)
  • Multi-vehicle simulation
  • Comprehensive and intuitive API (Python, C# and C++ open source client)
  • Low-latency HIL
  • Advanced jamming and spoofing options
  • All GNSS constellations
  • Powerful Automation
  • Aerospace Simulation
  • User-defined waveforms

Orolia GSG-6GSG-5 and GSG-6 Series

Spectracom's GSG-5 and GSG-6 series are GPS, GLONASS, Galileo and BeiDou constellation simulators with a base of 4 channels, upgradeable to 8, 16 or more. Features:
  • Versatile multi-channel GNSS signal generator with pre-configured test scenarios
  • Includes advanced features such as SBAS (WAAS, EGNOS, MSAS, or GAGAN), white noise generation, multipath simulation
  • Operates with StudioView™ for easy scenario creation and file management
  • Fully operational via front-panel, web-based remote control, or SCPI protocol
  • Multiple interfaces for remote control
  • Affordable, powerful, and easy-to-use
  • SW upgradeable to more channels, more features, and other GNSS systems


Time and Frequency Synchronisation, Network Time Protocol Servers

SecureSync Synchronisation SystemsSecureSync 2400

The SecureSync Synchronization Systems are a modular time and frequency synchronization platform with those features:
  • Enterprise Class GPS/GNSS MasterClock (4th Generation)
  • 25.000 installations worldwide from Finance Datacenters to Security and Defense industry including Energy, Telecom, Broadcast, Sat Ground Stations, IT, Transport…
  • Modularity/Upgradability : this unit has 6 available slots to fit with 25 available option boards (input/output signals like 1PPS, NTP, PTP, IRIG, 1,2,5, 10 MHz, E1/T1, SAASM, STANAG, HaveQuick, NMEA, Event Broadcast, ...)
  • Extended Operating Temperature (-20°C to +65°C) and shock & vibration proof embedded STD-810F as standard
  • Webserver/SNMP traps embedded as standard
  • IT Security protocols embedded (LdaP, IPSec, Radius, HTTS, IPV4, IPV6…..)
  • 1x1PPS, 1x10MHz, 1xNTP outputs available as standard
  • New features recently provided: FO native outputs (1PPS, IRIG, PTP), 1 Gb PTP (copper and fibre), sinewave frequency mixer (from 1 Hz to 16 MHz), Glonass receiver (GPS and Glonass available in same unit)
  • NATO approved equipment
  • 5 years warranty
Download SecureSync 2400 datasheet

SecureSync IDM Suite

Orolia’s SecureSync Interference Detection Suite includes a package of jamming and spoofing detection algorithms.
  • No additional hardware required
  • Works with standard SecureSync GPS/GNSS receivers
  • Automatic switch to backup synchronization or holdover on detection of GPS/GNSS interference

NetClock Time Server / Master Clock

The Model 9483 NENA-compliant GPS master clock continues Spectracom's legacy of bringing essential time synchronization to public safety answering points (PSAPs) and other emergency and command and control systems.
  • Stratum-1 NTP v2, v3, v4 Time Server
  • Precision GPS time reference with internal OCXO
  • Ethernet 10/100 Base-T (additional 3-network Gig-E option)
  • Optional PTP master/slaves

GPS and Other Timing System Accessories

GPS/GNSS Antennas and Accessories Spectracom anti jamming GPS GNSS antenna
